– Quick & Easy Installation.

– Beautiful & Modern Design.

– Good Perspective, Unique 3D Shape, Smooth Lines.

– Strong Environmental Adaptability & Low Maintenance Cost.

– Diverse Color Options, The 3D fencing can be customized according to usage scenarios or needs.

– Products are professionally packaged to ensure safe transportation.

– Special pricing is available for bulk orders.

3D welded mesh fence panels are modern fence products with unique structures and excellent performance. This 3D curved fence is similar to our Rigid Mesh Fencing, but it uses a different bending method. First, the 3D fencing is meticulously crafted into mesh panels through precision welding technology.

• Unique 3D V-Bending: the panels are formed with several V-shaped bends (i.e. 3D curves).

• Superior Protection: Galvanized and powder-coated/hot-dip galvanized finish.

Innovative horizontal curves significantly enhance rigidity, impact resistance, and stability. The product is durable and not easy to fade in various harsh environments. The 3D fence has the advantages of fast and convenient installation, beautiful and modern appearance, good perspective, and low maintenance cost. It is an ideal choice for a variety of applications such as residential, commercial, industrial, and public places.

We offer a wide range of customization options, including size, color (referencing the RAL color chart), and surface treatment, ensuring our fence panels perfectly match your project drawings and site environment, minimizing on-site modifications and improving construction efficiency.

3D Fence Specifications

3D Wire Mesh Fence Panels Production Process

Galvanized Wire

Select high-quality steel wire that meets strength, toughness, and corrosion resistance requirements, such as galvanized steel wire. Stringent quality inspections are performed on the wire diameter, surface quality, and coating thickness.

Straightening and Cutting

The coiled galvanized steel wire, when passed through a high-precision automatic straightening machine, effectively removes its inherent curvature, achieving a straightness error of < 1 mm/m. Subsequently, it is cut to a specific length with high precision using a CNC length-cutting device, with the cutting length tolerance typically controlled within ±1 mm.

Wire Bending

Using CNC bending equipment, galvanized steel wire is bent into the desired arc shape. The bending process requires extremely high precision from the bending machine, demanding precise control of the bending angle, radius, and material deformation. The bending angle error is controlled within ±0.5°, and the bending radius error is controlled within ±1mm, to ensure the accuracy and consistency of the arc shape.

Mesh Welding

Automated welding equipment is used to place the cut wire on the welding machine’s feed rack. The machine welds the intersections of the wires, forming strong welds. Full automation ensures uniform mesh size and weld strength.

Surface Treatment

After welding, the edges and welds are ground to remove burrs, oil, slag, and other impurities, preparing for subsequent coating.

Powder Coating

Based on hot-dip galvanizing, a dense and robust powder coating with a thickness of approximately 80-120 micrometers is formed through a precise spraying process. This coating significantly enhances the fence’s corrosion resistance, UV resistance, and mechanical strength.

Quality Control

Check whether the dimensions of the fence panels meet the design requirements, including length, width, height, and bending angle. Check whether the welding points are firm and free from defects such as incomplete or missing welds. Check if the coating is uniform and smooth, and free from bubbles, scratches, or peeling.

Packaging

Wrap the fence panels with plastic film or bubble wrap to prevent scratching or damage during transportation. Stack the fence panels on wooden or steel pallets and secure them with strapping for easy loading and unloading.

Advantages of 3D Fence Panels

• Strong & Stable Structure: The V-bend design significantly enhances the panel’s bending strength and overall stability.

• Excellent Anti-Corrosion Performance: High-quality galvanizing and powder coating double protection, effectively resisting rust and chemical erosion.

• Strong Welding Points: Precision welding technology ensures that each connection point is tight and not easy to fall off.

• Strong Impact Resistance: The strong grid structure and enhanced rigidity enable it to withstand certain external impacts.

• Excellent Weather Resistance: Adapt to bad weather such as sun, rain, temperature changes, etc.

• High Safety: The structure is not easy to climb, providing effective safety protection.

• Standardized Production: Produced using automated equipment, the 3d fencing size is consistent and the quality is stable.

3D Fence Product Applications

• Residential Areas & Villas.

• Commercial Areas & Office Parks.

• Schools & Playgrounds.

• Along Roads & Railways.

• Stadiums: Peripheral Fences or Site Isolation.

• Public Facilities, Airports, Ports, or other areas.
